Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They make machinery such as aerial lifts, manlifts and boom lifts. These equipments are designed to facilitate access to difficult to reach places, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves only in one direction and contains handholds or platforms or steps which are connected to the unit to be able to transport workers from every floor.
TB85
The TB85 man lift by Terex provides a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions which measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This model offers a reach of seventy feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
